LCF-101 | Lens Foot for Sony FE 100-400mm f/4.5-5.6 GM OSS

SKU LCF-101
$100.00

Out Of Stock. Back-Order OK

Details

LCF-101 for Sony FE 100-400mm f/4.5-5.6 GM OSS and FE 70-200mm f/2.8 GM OSS

Overview

The LCF-101 lens replacement foot with built-in-dovetail mounting made specifically for the Sony FE 100-400mm f/4.5-5.6 GM OSS and Sony FE 70-200mm f/2.8 GM OSS lenses will be lighter, lower in profile, and provide the best possible stability for your lens. The Really Right Stuff LCF-101 foot replacement is precision machined from a solid block of 6061-T6 aluminum and is fully compatible with 1.5" RRS Dovetail Standard. This updated foot (updated design based on LCF-100) replaces the Sony lens collar foot on Sony FE 100-400mm f/4.5-5.6 GM OSS and FE 70-200mm f/2.8 GM OSS Lens.

1. To remove the Sony foot, unscrew the lock knob, depress the spring-loaded tab, and slide the foot forward.
2. To install the LCF-101, slide it on from front to back until you feel it snap into place, then tighten the lock knob.

Features

  • RRS Dovetail Standard
  • CNC machined 6061-T6 Aluminum
  • Anodized; Type II Black
  • 3/8" threaded accessory mounting socket
  • 1/4"-20 threaded accessory mounting socket
  • Integrated QD (Quick Detach) socket

Specs

  1. Length 4.3"/ 109mm
  2. Height: 1.4"/ 35mm
  3. Width: 2.1"/ 52mm
  4. Weight: 2.8oz/ 79g

In the Box

  1. (1) LCF-102 Lens Foot
  2. (2) Safety Stop Screws
  3. (1) M2.5 hex key
